Wattage MiG-15


Overview

This R/C Model was got on Yahoo Auction, Original is released few years ago. Now this Mig-15 is not available Wattage R/C model. However EDF Unit on this model is enJet56. enJet56 is powerfull EDF that is input over 200W and static thrust is more than 500g. It means that is able to climb 90 degrees. Which is faster F-86 Saber or Mig15 ?
Type
380 Class Electric Duct Fan Jet
Specification
ESC Hyperion TITAN 30A Cont. 33A Burst 30g
Receiver MKS-PRO-RX8-72 7.2g
Servo
W-60B × 2
13.2g
W-084 8.4g
Size
Length 660mm
Wingspan 750mm
Wing Area 9.3dm²
Net Weight 327g
Zeta Plus
1000mAH 94g
Flying Weight 421g
Wing Loading 45.27g/dm²
Hyperion LVX
1500mAH 128g
Flying Weight 455g
Wing Loading 48.92g/dm²
Zeta Plus
1700mAH 151g
Flying Weight 478g
Wing Loading
51.40g/dm²
Power
10.98V 20.95A 225.67W


Power Unit

Item
Model
Actual Mesurement

BL Motor
enPower-450DFⅡ 4850 kv 20.95A(230.45W)
68g
Duct Fan Unit
en-JET56
29g
Battery Hyperion LVX 1500mAH 20C-30C
128g
Zeta Plus 1700mAH 16C-20C
151g
Static Thrust more than 540g
Amps - rpm graph
