| Type |
Pusher
Flying Wing |
||||||||
| Specifications |
|||||||||
| Motor | Spin Max(Suppo)
2212/6 |
31g |
|||||||
| Propeller |
APC S400 5.25x6.25 |
High Speed |
N/A |
||||||
| APC E 6x4 |
High Thrust |
N/A |
|||||||
| Battery | ZIPPY Compact 850mAh
3S 35C, HP LVX 8003S or W-L0870LITE-3S |
68 - 73g |
|||||||
| ESC |
HP 30A |
20g |
|||||||
| Receiver | Corona RP4D2 |
5g |
|||||||
| Sarvo |
9g servo x 2 |
18g |
|||||||
| Size |
Length |
465mm |
|||||||
| Wingspan |
876mm | ||||||||
| Wing Area |
15.6dm² | ||||||||
| Flying
Weight |
300g | ||||||||
| Wing loading |
19.23g/dm² | ||||||||
| APC E 6x4 Static
Thrust |
22.95A
19230rpm Prop. Speed 117km/h Efficiency 76.0% |
791.6g |
|||||||
| Product URL | http://www.aircraft-japan.com/Datasheet/ja/wr-minibee.htm |
||||||||
|
|||||||||
| Video | |
![]() |
"Blade Bee" is able to fly for
about 10min. Speed is over 80km/h , may be (^^;) I can enjoy
quick response and high speed flight. When you look the video, you can
find climb angle over 70°. Also XPD-8 EDF jet flying wing has very nice
performance. |
